Copper Lug
Copper Lug 35mm² M10 Stud - 50 Pack
Copper cable lugs are used to terminate the ends of the electrical cable so they can be connected to other electrical equipment, such as busbars and electric motors. Cable lugs are highly conductive and can handle very high currents. Our range of Copper Lugs/Links complies to Australian & New Zealand standard AS/NZS4325 Part 1:1995.
Features and Benefits
- Wide range of sizes
- Can be crimped using handheld crimper or hydraulic crimper
- Easy insertion of a cable
Specifications
| QUANTITY IN PACK | 50 |
| CONDUCTOR SIZE | 35mm² |
| STRANDING METRIC | 19/1.53 |
| STUD | M10 |
| IDÂ SIZE | 8.4 |
| PALM WIDTH | 18mm |
| BARREL LENGTH | 21mm |
| FULL LENGTH | 45mm |
| A/F HEX | 9.2 |
| MATERIAL | Copper Grade C11000 |
| CONDUCTIVE MATERIAL | Copper 99.9% pure Oxygen content 30 p.p.m Max. Tensile strength 205 Mpa Min Ductile rating 40% Final metal state fully annealed Electroplating material tin 99.9% pure Other metals lead + antimony Thickness 5 -10 microns |
| TOTAL CONDUCTIVITY | 99.9% IACS |
| TOTAL RESISTIVITY | 1.72 micro-ohm cm |
| OPERATING TEMPERATURE | -55°C to 155°C due to oxygen-free copper |
| COMPLIANCES | AS/NZS4325 Part 1:1995 |
