ATV Weed Sprayer with Trailer – Self-Priming Pump

ATV Weed Sprayer Spot Spray Tank Range 2

RRP $549.95

$416.95

SAVE 24%

Splash Pass Members Only

Member price $375.25 AUD

Earn $37.53 Splash Pass credit on this order

Join Splash Pass — Free Sign in

capacity

Description

Large-area weeding made effortless, one ride at a time.

If you've ever spent a long afternoon fighting weeds across a sprawling paddock, lawn or property, you already know the job demands more than a backpack sprayer and a steady arm. The ATV Weed Sprayer with Trailer is built for exactly that kind of territory — turning a labour-intensive chore into a smooth, one-handed pass across your land. Mount it to your ATV, quad bike or mower, open the throttle, and let the self-priming pump do the heavy lifting.

What sets this sprayer apart is the flexibility it brings to the job. The adjustable boom rack lets you dial in your spray pattern to match the area you're covering, while the handheld spray lance gives you the precision to spot-treat without dismounting. Whether you're blanketing a large paddock or targeting a stubborn patch along the fence line, you have the right tool in hand for both. The chemical-grade hose and multi-nozzle boom rack work together to keep coverage consistent, even and thorough from start to finish.

The included trailer carries a serious load capacity, and the tank sits low for a stable, balanced ride across uneven ground. Ratchet straps make mounting straightforward, so you spend less time setting up and more time getting the job done.

Select your preferred option above to view exact specifications.

Features

Self-priming pump delivers powerful, consistent spray pressure
Adjustable boom rack with multiple nozzles for broad, even coverage
Handheld spray lance connects via chemical-grade hose for spot spraying
Compatible with ATVs, quad bikes and mowers via ratchet strap mounting
Included heavy-duty trailer with 150kg load capacity
Low-profile tank design for improved stability on uneven terrain
Adjustable design to suit a wide range of spraying requirements

Product Code : DZ-HR22-DZ-12729

SKU : HR22-DZ-12729

Dimensions & Specification

Specifications:

Volts: 12V
Power: 65W
Trailer Capacity: 150KG
Spray boom length: 1.5M
Spray boom hose: 1.5M
Effective boom spray width: 1.5 - 2.5m
Tank capacity: 100L
Diaphragm pump: 108PSI/7.5BAR Self Priming
High pressure hand held spray hose: 5M
Hand held spray gun range: 8m
Spray lance length: 68cm
Maximum pressure: 130 PSI / 9 BAR
Spray lance pressure & flow rate: 4.5 Bar at 2.6L/min
Spray gun pressure & flow rate: 3.5Bar at 3.1L/min (MAX 5.5BAR, adjustable)
Spray nozzles: 4 on the boom
Adjustable spray nozzle (on lance): Stream/ Jet
Fasten strap: 5m
Lance nozzle: Brass
DC cable with clamp: 5M
Pressure gauge capacity: 150psi

Features

Features:

150KG capacity trailer with pneumatic tyres
Adjustable boom rack
Can be mounted on ATVs, quad bikes and mowers
Durable and leak-proof 100L tank
Impact-resistant, rust-proof and UV-stable design
Rust-resistant stainless steel spray tube and boom
Wide 8m spraying range
108psi self-priming pump
Two spraying modes: Jet/ Stream
5m high pressure chemical-grade hose
Built-in run-dry protection
Filling inlet with ultra-fine filter
Superior corrosion-resistant brass fittings
Low tank profile for optimal stability
Ratchet fasten straps included
Rear spray boom with nozzles included
Hand-held spray nozzle included
One year warranty

What's Included

1 x 100L spray tank
1 x Heavy duty trailer
1 x Self-priming DC pump
1 x 1.5m boom hose
1 x 5m spray hose
1 x 1.5m boom w/ 4 nozzles
1 x Spray lance
1 x 5M DC cable
1 x Fasten strap
1 x 150 Psi pressure gauge
1 x Manual
